Denture Bases

model not adhering to platform check support position check the printer ui to ensure your parts were supported above platform, and that the proper support sop was followed dentca denture base ii for carbon printers docid\ infir883sjilyouwet4nq desktop health flexcera base and flexcera base ultra+ docid\ pr5ek3rwsxsxdegugfsde lucitone digital print 3d denture base resin docid\ gegvfyfls9bkhfa2wvvju platform maintenance check to ensure your platform is seating correctly m2 maintenance docid 0ywe7ymsiydn imldvtpn maintenance docid 0ywe7ymsiydn imldvtpn m3/m3 max weekly docid\ imuk y8klpc7qpxku6yyk expired resin check the expiration sticker on your resin bottle to ensure your resin is not past its expiration date if it is, dispose of the resin and print again with a non expired bottle check alignment if you are still experiencing issues with parts consistently falling off the platform, your printer may be out of alignment as a very basic test, you can run an an printer health checks or a printer health checks to see if there are any large issues with your printer's alignment the alignment test print is more appropriate when adhesion is observed to vary across the build plane the z stroke calibration test print shows adhesion is uniformly poor across the build plane printer health checks docid\ eneydjvgk9i1zhog5jjje printer health checks docid\ eneydjvgk9i1zhog5jjje please send the results to carbon support docid\ k86zo5vcyn wqjl3vdgft to determine if alignment may be contributing to the print failures still having trouble? contact carbon support docid\ k86zo5vcyn wqjl3vdgft part is deformed check supports check the printer ui to ensure your parts were supported according to the guidance dentca denture base ii for carbon printers docid\ infir883sjilyouwet4nq desktop health flexcera base and flexcera base ultra+ docid\ pr5ek3rwsxsxdegugfsde lucitone digital print 3d denture base resin docid\ gegvfyfls9bkhfa2wvvju check the slices check the project analysis docid\ gfr goc irq l9 kanc x in the printer ui to ensure the model does not have any errors if errors are detected, use your 3rd party software tool to repair them still having trouble? contact carbon support docid\ k86zo5vcyn wqjl3vdgft with a print error teeth are not fitting into the denture bases check teeth sockets check the teeth sockets for any remaining support nubs if the vertical orientation was used if any are still protruding, file them down and reseat the teeth check printed teeth ensure that the teeth printed correctly and are not deformed check designs check your design settings in your cad design software to ensure that your stl is correct bonding process review the bonding process in the dentca denture base ii for carbon printers docid\ infir883sjilyouwet4nq to ensure that all of the steps were followed correctly still having trouble? contact carbon support docid\ k86zo5vcyn wqjl3vdgft with a print error denture base is not fitting the model well try different orientation for dentca denture base ii only if the initial print was oriented using the 15 and 30 degree angled orientations, try printing the denture in the vertical orientation, as this yields improved accuracy see dentca denture base ii for carbon printers docid\ infir883sjilyouwet4nq review base design the denture may have been designed in a way that prevents proper fit from being achieved have an experienced designer confirm that the design is sufficient stone models dentures are sometimes designed to grip undercuts stone models are very rigid, and sometimes prevent a denture from fully seating still having trouble? contact carbon support docid\ k86zo5vcyn wqjl3vdgft with a print error other issue for any other issue, contact carbon support docid\ k86zo5vcyn wqjl3vdgft be sure to provide as much detailed information as possible in order to expedite the diagnostic process
