Pac-Dent Rodin Bite Tray

overview this resin is designed for printing custom full and quadrant maxillary and mandibular arch impression bite trays for use with pvs, vps, and alginate impression material systems a robust formulation yields a final product having excellent surface finish, accuracy, and material properties resource links about the material manufacturer instructions for use safety data sheet protocol this downloadable handout provides important usage information, including instructions about s torage dispensing washing curing print it out and bring it into the lab example protocol sheet handout https //archbee doc uploads s3 amazonaws com/vmzsbejdeghbwm j2w3hr eyuarfuhs8eoffw3gtdak 20240910 201644 pdf dental post processing grids one of our most popular downloads! this table provides washing and curing instructions for all supported dental resins print it and use it in the lab as a quick reference images of dental post processing grids english https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm 5vxy9axkpgf5gyc4v6k7y 20250514 183905 pdf german/deutsch https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm sebslaiwuzndri1gcllop 20241125 214312 pdf spanish/español https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm 2i0uhzofua4ayjfusl1v2 20241203 180542 pdf digital preparation connect to printer connect to the printer using your web browser open browser carbon recommends the latest version of google chrome type https //print carbon3d com in the url field carbon recommends bookmarking this site for later use if you are not automatically logged in, enter your email and password and click log in enter your email and password and click log in if you have multiple printers, click the printer that you wish to use click the printer that you wish to use import parts click new project you can also drag your files from a file browser window and drop it on top of the new project icon enter a new project name in the resin dropdown for aox indications, select pac dent rodin bite tray toggle auto nest dentures off only use encrypt project if you want to require a password to access the project note carbon cannot provide support for encrypted projects drag and drop your files into the dotted box dotted box or click browse your files and select them in a file browser window click create after a few moments you will see the main printer interface with your dentures on the platform orientation orient the impression trays vertically with tab on platform orient the impression trays vertically with tab on platform this orientation yields the best accuracy, requires the fewest supports and allows the most parts per build snap to platform the snap to platform feature enables automatic alignment of a selected surface with the platform this feature is the best way to quickly and accurately orient the flat side of the tab to the platform click orient orient or shift + o in the main bar in the printer software click select surface select surface the button will change to done click on the flat underside surface flat underside surface of the part that you want to align with the platform click on done to exit snap to platform tool supporting enter support mode supports hold up the part during printing they do this by connecting platform facing surfaces to the platform click support or shift + s support or shift + s in the dark gray bar at the top of screen under position , select on platform on platform to lift parts off the platform under auto support method , select basic basic click generate generate to automatically create supports this may take seconds or minutes depending on the complexity of your part note we recommend using the basic support method instead of advanced for impression trays the advanced method’s fea processing takes about 30 minutes for each tray typically, using basic auto supports and manually editing takes 5 20 minutes based on skill level with no drop in part quality check the supported tray the auto support function aggressively adds supports to your part in order to ensure print success since supports leave small bits or nubs after removal, they reduce part accuracy therefore, supports usually need manual editing to eliminate them from important surfaces and features examine your newly supported model note any supports that contact any intaglio surface contact any intaglio surface contact any other critical feature use the edit edit feature to remove any unwanted supports edited supports these are before/after images of the tray before editing and after editing before editing many supports on intaglio surfaces before editing many supports on intaglio surfaces after editing no supports on intaglio surfaces after editing no supports on intaglio surfaces fence supports fences work well for impression trays they are easy to remove they do not increase the footprint of the part, which allows more trays to be built at once click on fences fences click a series of points series of points on the tray to define the fence use overhang detection overhang detection to find areas that need support click generate generate to create the fence geometry repeat as needed carbon recommends running fences every 2 4 mm on horizontal or near horizontal surfaces well supported trays this is an example of an impression tray that is well supported with fences supported on the platform provides stability lower than printing above platform so print times are shorter fewer supports require less resin intaglio surfaces are free from supports print controls do not change any of the settings under print controls the default settings deliver the best results for impression trays slicing slice thickness should stay at standard (100 µm) standard (100 µm) reducing the slice thickness by choosing the fine (50 µm) or super fine (25 µm) settings will dramatically increase print time and may reduce part quality and accuracy project analysis select the project analysis project analysis tab click start analysis and wait for the processing to complete note the required resin volume and print time click add to queue manufacturer instructions for use manufacturer instructions for use questions & support rodin bite tray for questions about the resin properties, printing, washing or curing your impression trays, please contact the pacdent technical team email info\@pac dent com phone 1 909 839 0888 carbon for questions about your carbon printer or carbon software settings used for this resin, please contact carbon email support\@carbon3d com through your user interface by choosing “request help” in the prints page
