Dental Materials

KeyPrint KeyGuide

37min
overview keystone industries® keyprint® keyguide™ is now available to produce surgical guides the material is a rigid, biocompatible resin and is ideal for fast production this course will cover the digital prep of your guides to properly prepare them for printing this resin is not currently compatible with the ao polishing cassette docid\ iffh3q8 wlk liqr87bd5 resource links about the material manufacturer instructions for use safety data sheet protocol this downloadable handout provides important usage information, including instructions about s torage dispensing washing curing print it out and bring it into the lab example protocol sheet handout english https //archbee doc uploads s3 amazonaws com/xcoi3p6o5jo0mvhohv9ro wtui5 rf7sie9s 9ud03e 20240919 100929 pdf german/deutsch https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm l 0hm2jquqvcvqatdqyap 20241217 011137 pdf spanish/español https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm f ox3zrtj7jxqu4safmxg 20241217 011114 pdf dental post processing grids one of our most popular downloads! this table provides washing and curing instructions for all supported dental resins print it and use it in the lab as a quick reference images of dental post processing grids english https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm mrhbajqatds qt4qdwu9l 20250505 221416 pdf german/deutsch https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm sebslaiwuzndri1gcllop 20241125 214312 pdf spanish/español https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm 2i0uhzofua4ayjfusl1v2 20241203 180542 pdf performance qualification certificate download the certificate here general orientation & support information hide the platform use toggle platform (or press b ) to hide the platform before orienting parts this will make it easier to see overhangs and place supports use patch and fence tools to create supports patch tool the supports speeds up support creation by automatically supporting an area with just a few clicks it is useful for supporting larger areas of overhang that would take longer to support manually it is often useful to support your parts with this tool before manually adding supports fence tool supports are manually placed by the user and are best suited on linear overhangs or smaller areas fences provide stability while leaving smaller nubs than the default bars option review supports docid\ vubpoaitblm11am9 qj1p in printer ui docid\ oid4znztzyelttpvj984a course for more information arch & full palate orienting arches and full palates should be rotated 40 degrees 40 degrees with the anterior of the guide rotated away from the platform workflow 1 click on orient or shift + o in the top bar in the printer interface 2 in the lower right corner of the bottom bar, turn on overhang detection or v key and set to 40 degrees areas that need support will appear red red 3 orient the model so that the intaglio surface is facing the platform 4 adjust the model so that it is mostly parallel with the platform 5 rotate the surgical guide so that the anterior is at a 40 degree angle from the platform supporting strategy fence placement along the guide perimeter around drill holes on important features such as articulators 2 rows of fences are recommended on features wider than 3 mm fence free zones intaglio surfaces interior of drill holes interior of windows any critical surfaces check critical surfaces before creating supports, check the critical surfaces of your part to ensure that supports will not be needed overhang detection will show surfaces that may need supports by coloring them red click on the overhang detection (v) tool at the bottom of the screen to activate it leave the default value at 40 degrees click the toggle platform (b) tool to hide the platform for unobstructed viewing of the underside of the model check critical areas , especially inside drill holes, to make sure those surfaces do not require supports some intaglio surfaces will be red but these areas will not require supports if critical areas are red, tilt up the part slightly 1 3 degrees and recheck repeat until critical areas are free of red enter support mode and select fence surgical guides require precise placement of supports because of this, we recommend manually adding fence supports fences are ideal for supporting surgical guides of all types (arches, full palettes and quads) easy to remove contact points are small and require little finishing do not use automatic supports this mode will cover a large portion of the intaglio surfaces, which will result in an unusable part click support in the dark gray bar at the top of screen under position , select above platform to lift parts off the platform under the manual tab select fence support perimeter click a series of points along the entire perimeter of the arch carbon recommends using a single, long fence for easier removal a sequence of 2 or more short fences is acceptable use overhang detection to find areas that need support to move points, click esc key then hold down e key click on a point and move it to a new location repeat as needed to add additional fences click generate to create the fence geometry additional supports continue adding fence supports to these features bars bars wide areas wide areas (offset from perimeter fence by 2 4 mm) articulators articulators any other critical features ensure that the following surfaces are free from fences intaglio surfaces interior of drill holes interior of windows any critical surfaces quad orienting either end (posterior or anterior) of the quad should be rotated 40 degrees 40 degrees off of the platform workflow 1 click on orient or shift + o in the top bar in the printer interface 2 in the lower right corner of the bottom bar, turn on overhang detection or v key and set to 40 degrees areas that need support will appear red red 3 orient the quad so that the intaglio surface is facing the platform 4 adjust the quad so that it is mostly parallel with the platform 5 make sure that the quad is parallel with the left/right sides of the platform 6 rotate the quad so that it is at a 40 degree angle from the platform either the anterior or posterior of the quad can be rotated off of the platform supporting check critical surfaces before creating supports, check the critical surfaces of your part to ensure that supports will not be needed overhang detection will show surfaces that may need supports by coloring them red supporting quads 1 support entire perimeter of quad perimeter of quad with fence supports we recommend using a single, long fence for easier removal a sequence of 2 or more short fences is acceptable 2 create secondary lines of fences secondary lines of fences on wide areas offset from perimeter fence by 2 4 mm where possible 3 support other critical features other critical features ensure that the following surfaces are free from fences intaglio surfaces interior of drill holes interior of windows any critical surfaces properly oriented and supported surgical guides intaglio surfaces facing platform supported above platform fences around part boundary arch/full palate rotated 40 degrees with posterior tilted towards platform quad rotated 40 degrees with either anterior or posterior tilted towards platform nesting select the layout tab layout tab (shift + l) in the top menu bar under auto layout, select gen2 gen2 gen2 usually gives the most effecient packing for dental devices enter at least 1 mm 1 mm in padding padding models require a minimum of 1 mm of space between them leave optimize starting rotation unchecked this leaves your parts in their previous orientations leave allowed rotations at the default setting this gives the software maximum flexibility to fit the most possible parts on the build platform press the auto layout auto layout button to arrange your parts screen shot showing button locations if necessary, nesting can be changed manually click and drag parts to adjust their position modify z rotation by using the spin tool or manual rotations under the orient tab (shift + o) use the part list tab as needed to more easily select models and focus on them print preparation print controls click print controls print controls or shift + p shift + p in the top menu bar slicing slice thickness should be standard (100 µ) reducing the slice thickness by choosing the fine (50 µ) or super fine (25 µ) settings will increase print time and may reduce part quality and accuracy project analysis select the project analysis project analysis tab click start analysis and wait for the processing to complete note the required resin volume and print time click add to queue manufacturer instructions for use manufacturer instructions for use questions & support for questions about the resin properties, printing, washing or curing your parts, please contact the keystone support team email customerservice\@keystoneind com phone u s and canada 1 800 333 3131 eu +49 77 31 91 21 01 for questions about your carbon printer or carbon software settings used for this resin, please contact carbon email support\@carbon3d com phone 1 (650) 285 6307 option 2 printer ui on the dashboard, select the prints prints tab select one of the printed projects select one of the printed projects click request help request help in the lower right corner
