Lucitone Digital IPN 3D Premium Tooth
30 min
overview lucitone digital ipn™ 3d premium tooth resin is now available for carbon m series printers to produce teeth for dentures when paired with lucitone digital print™ 3d denture base, you can create complete denture appliances with dls lucitone digital ipn 3d premium tooth resin comes in the following shades a1, a2, a3, a3 5, b1, bl3, c1, & c2 ten additional shades (a4, b2, b3, b4, bl1, c3, c4, d2, d3, & d4) will be released on a rolling basis this guide will cover the preparation of your digital denture teeth models to adequately prepare them for printing with lucitone digital ipn™ 3d premium tooth resin this resin is compatible with the docid\ iffh3q8 wlk liqr87bd5 follow the link to learn about specific post processing requirements see ao polishing cassette docid\ iffh3q8 wlk liqr87bd5 for post processing information specific to the ao polishing cassette resource links https //www carbon3d com/materials/lucitone digital ipn 3d premium tooth https //www dentsplysirona com/content/dentsply sirona dt/en/en/customer support/download center/download details html?assetpath=/content/dam/master/product procedure brand categories/procedures/dental lab/removable prosthetics/lucitone digital print denture system/ifu/lab ifu supplement insert lucitone digital print denture system en de it fr es dp 0000566 rev6 2023 01 pdf https //www dentsplysirona com/content/dentsply sirona dt/en/en/customer support/download center/download details html?assetpath=/content/dam/master/product procedure brand categories/lab/product categories/denture teeth/sds/lab sds lucitone digital ipn 3d premium tooth en us can pdf protocol this downloadable handout provides important usage information, including instructions about storage, washing and curing print it out and bring it into the lab! dental post processing grids one of our most popular downloads! this table provides washing and curing instructions for all supported dental resins print it and use it in the lab as a quick reference images of dental post processing grids english german/deutsch spanish/español general orientation & support information hide the platform use toggle platform (or press b ) to hide the platform before orienting parts this will make it easier to see overhangs and place supports use patch tool to create supports patch tool the docid\ vubpoaitblm11am9 qj1p speeds up support creation by automatically supporting an area with just a few clicks it is useful for supporting larger areas of overhang that would take longer to support manually it is often useful to support your parts with this tool before manually adding supports review docid\ vubpoaitblm11am9 qj1p in docid\ oid4znztzyelttpvj984a course for more information orientation anterior teeth setup orient the 2 anterior sections so the root side is facing the platform root side is facing the platform position the camera so you are looking straight down on the platform push the reset camera icon reset camera icon in the lower left corner of the screen to return to the default view push ▲ to look straight down ▲ to look straight down at platform adjust the sections so they are mostly parallel with the front edge of the platform mostly parallel with the front edge of the platform (x axis) make sure that the lingual region of each section is facing the lower portion of the screen lingual region of each section is facing the lower portion of the screen final orientation enter 45 45 into the x axis field the lingual side of the teeth sections will rotate 45 degrees toward the platform alternately, click on the x axis loop and rotate the teeth 45 degrees see docid\ rmnxtq1niahxzoc4bzxwu for more information posterior teeth orient the 2 anterior sections so the root side is facing the platform root side is facing the platform position the camera so you are looking straight down on the platform push the reset camera icon reset camera icon in the lower left corner of the screen to return to the default view push ▲ to look straight down at platform adjust the sections so they are mostly parallel with the side edges of the platform mostly parallel with the side edges of the platform (y axis) orient the sections so the occlusal surfaces are roughly parallel with the platform occlusal surfaces are roughly parallel with the platform enter 20 into the x axis field the lingual side of the teeth sections will rotate 20 degrees toward the platform the lingual side of the teeth sections will rotate 20 degrees toward the platform alternately, click on the x axis loop and rotate the teeth 20 degrees see docid\ rmnxtq1niahxzoc4bzxwu for more information full arches the arch should be roughly parallel roughly parallel with the platform because full arches are organic surfaces with no well defined flat areas, we do not recommend using snap to platform make sure that the anterior region of the arch is facing the upper portion of the screen anterior region of the arch is facing the upper portion of the screen enter 30 into the x axis field the lingual side of the teeth sections will rotate 30 degrees toward the platform the lingual side of the teeth sections will rotate 30 degrees toward the platform alternately, click on the x axis loop and rotate the teeth 30 degrees see docid\ rmnxtq1niahxzoc4bzxwu for more information supporting enter support mode click support in the dark gray bar under position, select above platform to lift parts off the platform make sure patch is selected note do not use automatic supports this will create bar supports bar supports that leave large nubs on tooth surfaces and do not provide adequate accuracy remember to turn off the platform using toggle platform (or press b) this will make it much easier to see the underside of the parts anterior and posterior teeth click on the basal side of the teeth to be supported the patch settings will now appear in the right menu set overhang angle to 50 degrees set primary support fill type to boundary fence only if needed, continue clicking on remaining basal surfaces until all overhangs are selected green indicates current selection and light purple shows previous selection(s) click generate all to create the supports well supported examples anterior posterior full arches click on the basal side of the teeth to be supported the patch settings will now appear in the right menu set overhang angle to 50 degrees set primary support fill type to bar (default) set spacing to 5 mm (default) make sure boundary fence is checked (default) set margin to 0 mm (default) continue clicking on remaining basal surfaces until all overhangs are selected green indicates current selection and light purple shows previous selection(s) click generate all to create the supports well supported example intaglio lingual nesting select the layout tab layout tab (shift + l) in the top menu bar under auto layout, select gen2 gen2 gen2 usually gives the most effecient packing for dental devices enter at least 1 mm 1 mm in padding padding models require a minimum of 1 mm of space between them leave optimize starting rotation unchecked this leaves your parts in their previous orientations leave allowed rotations at the default setting this gives the software maximum flexibility to fit the most possible parts on the build platform press the auto layout auto layout button to arrange your parts screen shot showing button locations if necessary, nesting can be changed manually click and drag parts to adjust their position modify z rotation by using the spin tool or manual rotations under the orient tab (shift + o) use the part list tab as needed to more easily select models and focus on them print preparation print controls click print controls print controls or shift + p shift + p in the top menu bar slicing select standard (50 µ) this setting also applies to prints made with the ao polishing cassette carbon has only validated 50 µ slice thickness for this resin project analysis select the project analysis project analysis tab click start analysis and wait for the processing to complete note the required resin volume and print time click add to queue manufacturer instructions for use https //www dentsplysirona com/content/dentsply sirona dt/en/en/customer support/download center/download details html?assetpath=/content/dam/master/product procedure brand categories/procedures/dental lab/removable prosthetics/lucitone digital print denture system/ifu/lab ifu supplement insert lucitone digital print denture system en de it fr es dp 0000566 rev6 2023 01 pdf questions & support for questions about the resin properties, printing, washing or curing your denture teeth, please contact the dentsply sirona technical team email prosthetics customerservice\@dentsplysirona com phone 1 844 848 0137 for questions about your carbon printer or carbon software settings used for this resin, please contact carbon email mailto\ support\@carbon3d com phone 1 (650) 285 6307 option 2 printer ui on the dashboard, select the prints prints tab select one of the printed projects select one of the printed projects click request help request help in the lower right corner
