overview dreve fotodent® ibt for carbon printers is now available to produce indirect bonding trays the material is a clear, biocompatible resin and is ideal for fast production this guide will cover digital pre processing of your ibt devices to properly prepare them for printing with fotodent® ibt for carbon printers this resin is not currently compatible with the ao polishing cassette docid\ iffh3q8 wlk liqr87bd5 resource links about the material manufacturer instructions for use safety data sheet scroll to bottom of page and select safety data sheets protocol this downloadable handout provides important usage information, including instructions about s torage dispensing washing curing print it out and bring it into the lab example protocol sheet handout https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm hnfuyy29ncdlgqtlix5ep 20241004 162526 pdf dental post processing grids one of our most popular downloads! this table provides washing and curing instructions for all supported dental resins print it and use it in the lab as a quick reference images of dental post processing grids english https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm mrhbajqatds qt4qdwu9l 20250505 221416 pdf german/deutsch https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm sebslaiwuzndri1gcllop 20241125 214312 pdf spanish/español https //archbee doc uploads s3 amazonaws com/uxbzokjjtgpphjapq8fvm 2i0uhzofua4ayjfusl1v2 20241203 180542 pdf design recommendations flat occlusal plane carbon strongly recommends creating devices with flat occlusal planes this maximizes yield while minimizing printing and post processing times flat and featureless occlusal plane flat and featureless occlusal plane creates a strong tray minimizes part failure due to adhesion issues minimum wall thickness of 1 mm minimum wall thickness of 1 mm for optimal print outcomes prevents breaking minimize part height minimize part height conserves resin minimizes print time parts should be solid avoids potential venting issues during printing that can lead to failure conformal occlusal plane if it is not possible to design a device with a flat occlusal plane, then conformal occlusal planes may be used be aware that conformal occlusal plane devices have the following effects part must be printed at angle relative to platform support structures are required 2 3x increase in print time relative to flat occlusal plane post processing time increases due to support removal minimum wall thickness of 1 mm minimum wall thickness of 1 mm for optimal print outcomes prevents breaking general orientation & support information hide the platform use toggle platform (or press b ) to hide the platform before orienting parts this will make it easier to see overhangs and place supports use fence tools to create supports fence tool supports are manually placed by the user and are best suited on linear overhangs or smaller areas fences provide stability while leaving smaller nubs than the default bars option review supports docid\ vubpoaitblm11am9 qj1p in printer ui docid\ oid4znztzyelttpvj984a course for more information orient & support flat occlusal planes proper orientation of indirect bonding trays is critical maximizes yield by minimizing print defects eliminates the need for supports and the accompanying labor and resin costs achieves the required accuracy and surface quality all indirect bonding trays should be oriented to be flat against the build platform orienting use snap to platform to ensure the flat base is aligned with the platform click on orient orient in the main bar in the printer software select the part to be oriented under snap to platform click the select surface button select surface button click anywhere on the flat base of the tray part click anywhere on the flat base of the tray part the printer software will automatically rotate the part base to be parallel with the platform automatically rotate the part base to be parallel with the platform use snap to platform on all parts to ensure the part base is flat against the platform even a small anlgle between the part and the platform may result in a failed print z rotation of tray parts as long as the base of the part is snapped to the platform, you have freedom to rotate the part in the z axis to suit your needs supporting indirect bonding tray parts with a flat occlusal plane do not require supports because they print directly on the platform properly oriented and supported ibt part all indirect bonding trays should be oriented to be flat against the build platform any orientation is acceptable orient & support conformal occlusal planes orienting ibts with conformal occlusal planes should be oriented 45 degree angle with anterior teeth furthest from the platform intaglio surface facing the platform perform an initial orientation of both bases so that they are roughly parallel with the platform click on orient orient in the main bar in the printer software orient each base so that the intaglio surface is facing the platform adjust the trays so that they are mostly parallel with the platform mostly parallel with the platform we recommend typing values into the xyz axis fields changing orientation with the mouse or snap to platform function is more challenging position the camera so you are looking straight down on the platform push the reset camera icon reset camera icon in the lower left corner of the screen to return to the default view push ▲ to look straight down ▲ to look straight down at platform make sure that the posterior region of the tray is facing the lower portion of the screen now perform the final orientation because indirect bonding trays with conformal occlusal planes are organic surfaces with no well defined flat areas, carbon does not recommend using snap to platform it is much easier to enter values directly into the orient fields click on the part to select it enter a value of 45 degrees 45 degrees into the x axis field the posterior posterior of the part should be touching the platform z rotation of tray parts you have freedom to rotate the part in the z axis to suit your needs supporting carbon recommends using fences to support ibt devies they are easy to remove and do not increase the footprint of the part, enabling more parts to be fit onto the build platform click support support in the main bar in the printer software under position, select above platform above platform to create room between the platform and the part skip auto support method auto support method as this mode is not recommended click manually add manually add to enter the support editing interface add fences you will now see the support editing view support the entire perimeter of the intaglio walls click toggle platform button toggle platform button in the lower tool bar to hide the platform this will enable better visibility during fence creation click the fence icon fence icon in the top menu bar click a series of points series of points on the base to define the fence use overhang detection overhang detection to find areas that need support carbon recommends making a series of small fences rather than making a single continuous fence to give greater flexibility to reposition points click esc key and then hold down e key to reposition points click generate generate to create the fence geometry this may take a few minutes see fences in printer ui for more information about the fence workflow properly oriented and supported ibt part 45 degree orientation with anterior teeth facing away from platform intaglio surface facing platform any z axis rotation is acceptable nesting select the layout tab layout tab (shift + l) in the top menu bar under auto layout, select gen2 gen2 gen2 usually gives the most effecient packing for dental devices enter at least 1 mm 1 mm in padding padding models require a minimum of 1 mm of space between them leave optimize starting rotation unchecked this leaves your parts in their previous orientations leave allowed rotations at the default setting this gives the software maximum flexibility to fit the most possible parts on the build platform press the auto layout auto layout button to arrange your parts screen shot showing button locations if necessary, nesting can be changed manually click and drag parts to adjust their position modify z rotation by using the spin tool or manual rotations under the orient tab (shift + o) use the part list tab as needed to more easily select models and focus on them print preparation print controls click print controls print controls or shift + p shift + p in the top menu bar slicing slice thickness should be standard (100 µ) reducing the slice thickness by choosing the fine (50 µ) or super fine (25 µ) settings will increase print time and may reduce part quality and accuracy project analysis select the project analysis project analysis tab click start analysis and wait for the processing to complete note the required resin volume and print time click add to queue manufacturer instructions for use https //innovation meditech de/fileadmin/medienablage/innovation meditech/downloads/fotodent downloads/gebrauchsinformationen/inst fotodent ibt de gb fr es it pdf?expired=1728061575 questions & support for questions about the resin properties, printing, washing or curing your parts, please contact the dreve technical team email support fotodent\@dreve com phone 952 358 3526 for questions about your carbon printer or carbon software settings used for this resin, please contact carbon email support\@carbon3d com phone 1 (650) 285 6307 option 2 printer ui on the dashboard, select the prints prints tab select one of the printed projects select one of the printed projects click request help request help in the lower right corner
